Overview
The DMM-900X Dual Spindle Beveling Machine delivers maximum throughput with twin 63mm cutter discs powered by 8400W total. When production volume and cycle time are critical, the dual-spindle configuration removes material twice as fast as single-spindle alternatives while achieving bevel widths up to 80mm in a single pass.
Key Advantages
- Dual 63mm cutters — Two spindles working simultaneously
- 8400W total power — Industry-leading output for aggressive cutting
- 80mm bevel width — Wide preparations in a single pass
- Full 0°-90° range — Complete angle flexibility
- 370kg heavy-duty frame — Stable dual-spindle operation
Technical Specifications
| Parameter | Specification |
|---|---|
| Clamp Thickness | 5-80mm |
| Bevel Angle | 0°-90° |
| Single Bevel Width | 1-35mm |
| Max Bevel Width | 80mm |
| Total Power | 8400W |
| Cutter Diameter | 63mm × 2 |
| Spindle Speed | 750-1050 r/min |
| Net Weight | 370kg |
Speed Reference (Q235 Steel)
| Thickness | Recommended Speed |
|---|---|
| 10mm | 950 r/min |
| 20mm | 900 r/min |
| 40mm | 850 r/min |
| 60mm | 800 r/min |
| 80mm | 750 r/min |
When to Choose DMM-900X
| Situation | Why DMM-900X |
|---|---|
| High production volume | Twin spindles double throughput |
| Wide bevels required | Up to 80mm in single pass |
| Thick plates (60-80mm) | 8400W power handles heavy cuts |
| Cycle time critical | Fastest material removal |
Customization Options
This machine can be tailored to your specific requirements:
- Bevel Angle — Custom cutter angles manufactured to match your welding specifications
- Capacity Range — Thickness range adjustable for your specific material requirements
- Drive System — Choose electric, pneumatic, or hydraulic based on your facility needs
Contact our engineering team to discuss your customization requirements.
